derul underwater ROV robot zero buoyancy floating cable Price

derul underwater ROV robot zero buoyancy floating cable

Specification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Inquire Now Next Product

INTRODUCTION

[derul underwater ROV robot zero buoyancy floating cable] Cable structure:

Conductor: Multi-strand finely twisted ultra-fine oxygen-free copper wire Insulation: Fluorine plastic insulation (can be customized) Color: ≤0.5mm2 color identification, brown, black, blue, purple, pink, orange >0.5mm2 black number white number number, Inner sheath for wires with yellow and green connections for more than 3 cores: Optional shielding: tinned copper mesh braided shielding, density above 85% Sheath: imported PUR material, color can be selected by yourself.

[derul underwater ROV robot zero buoyancy floating cable] Cable density:

1.0~1.1, using advanced technology to achieve a floating state of the cable itself in the water, without affecting the normal work of the underwater robot

[derul underwater rov robot cable] Some application parameters Rated voltage: U0/U < 0.5mm2 300/300 V ≥ O.5mm2 300/500 V Test voltage: U 3000V conforms to DIN VDE 0281 Part 2 Temperature range: ℃ Mobile installation : -45℃～+105℃ Fixed installation: -45℃～+105℃.

In addition to the electrical performance, weather resistance, and other basic requirements of underwater robot cables that can match the equipment, the most important basic feature is that they can withstand long-term bending movements and large-angle twisting movements to ensure normal operation. This is different from dragging. Chain cables etc. are different.

[derul underwater rov robot cable] Some application parameters Rated voltage:

U0/U < 0.5mm2 300/300 V ≥ O.5mm2 300/500 V Test voltage: U 3000V conforms to DIN VDE 0281 Part 2 Temperature range: ℃ Mobile installation : -45℃～+105℃ Fixed installation: -45℃～+105℃

ADVANTAGES

1) High flexibility - multiple strands of finely twisted oxygen-free copper wire are used as conductors to ensure the flexibility of the wire body;

2) Bending resistance - Optimized cable pitch + special structural design + careful selection of materials, suitable for high-frequency bending occasions without core;

3) Easy to use - the core wire insulation color, sheath color and cable length can be customized according to customer requirements;

4) Anti-electronic interference - the overall tinned copper wire braided shielding density is more than 85%, which effectively resists external high-frequency electromagnetic interference;

5) Tensile-flexible wrapping material-non-woven fabric wrapped wire body + anti-drawing wire filling, which effectively acts as a buffer when the cable bends back and forth;

6) Wear-resistant, oil-resistant and anti-aging - special flexible special sheath material (color can be selected by the customer) with a bending life of more than 20 million times without cracking.

7) Waterproof, acid and alkali resistance, radiation protection, and corrosion resistance—newly imported PUR sheath material, environmentally friendly material.

CUSTOMIZATION CAPABILITY

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Is Derul Cable a manufacturer or a trading company?

A: Derul Cable is a special cable manufacturer based in Shanghai.

Q: Is the price negotiable?

A: Yes, the price is negotiable according to the purchase quantity.

Q: What is the regular MOQ for the cable?

A: Any quantity is okay to purchase for product in stock. For product that need to be manufactured after the order, the MOQ is usually 100-200 m per type.

Q: How can I get samples?

A: After payment for the potential cost including express freight and the confirmation of the cable's dimension and structure , we will arrange for the sample and send directly to your door.

Q: Is OEM or ODM service available?

A: OEM and ODM services are both available. You may provide us with your requirement and we will evaluate it to push forward.

Q: What is the regular production time?

A: For regular quantity, it usually requires about 15-25 days to produce.
