High Quality Sensor Cable Supplier and Manufacturer-China Derul Brand Cable

Specification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Inquire Now Next Product

INTRODUCTION

Derul feedback encoder cable|Application scope:

Feedback and sensor shielded cables are mainly used in data and signal transmission, as well as in power supply chains, handling equipment and robot control projects. Can be used indoors and outdoors. Overall shielding ensures signal transmission and prevents electromagnetic interference.

DeRul feedback encoder cable|Product structure:

LiF12YC11Y(10×0.14/AWG+26+2×0.5/AWG20)

Wire: Super flexible stranded bare copper wire

Insulation: TPE core insulation

Core structure: core layered stranded tinned copper wire braiding

Wire core color: in accordance with D IN 47100 standards

Sheath material: PUR outer sheath

LiF12YC11Y(10×0.14/AWG 26+4×0.5/AWG 20)

Wire: Super flexible stranded bare copper wire

Insulation: TPE

Core structure: core layered stranded tinned copper wire braiding

Core color: 0.14mm²: white, brown, green, yellow, pink, blue, red, black, purple

0.5mm²: white, brown, blue, black LiF12YC11Y (15×0.14/AWG 26+4×0.5/AWG 20)

Wire: Super flexible stranded bare copper wire

Insulation: TPE

Core structure: core layered stranded tinned copper wire braiding

Wire core color: according to DIN 47100 standard

LiF12YD12YC11Y〔3×(2×0.14)/AWG26+2×(0.5)/AWG20〕

Wire: Super flexible stranded bare copper wire

Insulation: TPE

Core structure: 0.14mm²: cores are twisted in pairs, aluminum foil coated, tinned copper wire braided

0.5mm²: Individually shielded wire cores and twisted pairs, overall beryllium tin copper shielding, TPE sheath

Core color: 0.14mm²: green/yellow, yellow/pink, blue/red

0.5mm²: white, brown

Sheath material: PUR

DeRul feedback encoder cable|Technical description:

Working voltage: below 0.38mm²: 300V

0.50mm² or more: 500V

Minimum bending radius: 10×cable outer diameter

Temperature garden: mobile installation: -30℃ to +80℃

Insulation resistance: >100MΩ×Km

No harmful substances, compliant with RoHS standards

This product complies with the requirements of EEC Directive 73/23 (Low Voltage Directive) CE

ADVANTAGES

Flame retardant, hydrolysis and microbial resistance, oil, acid and alkali resistance, high flexibility, smaller outer diameter ensures a smaller bending radius and saves installation space

※Special customization can be provided for customers

CUSTOMIZATION CAPABILITY

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Is Derul Cable a manufacturer or a trading company?

A: Derul Cable is a special cable manufacturer based in Shanghai.

Q: Is the price negotiable?

A: Yes, the price is negotiable according to the purchase quantity.

Q: What is the regular MOQ for the cable?

A: Any quantity is okay to purchase for product in stock. For product that need to be manufactured after the order, the MOQ is usually 100-200 m per type.

Q: How can I get samples?

A: After payment for the potential cost including express freight and the confirmation of the cable's dimension and structure , we will arrange for the sample and send directly to your door.

Q: Is OEM or ODM service available?

A: OEM and ODM services are both available. You may provide us with your requirement and we will evaluate it to push forward.

Q: What is the regular production time?

A: For regular quantity, it usually requires about 15-25 days to produce.
